DMX-512 Master Bridge

DMXcas

Model Number: DMXcas

• Connects a standard DMX-512 master to a Casambi network

• Designed as a complement to casDMX
• Enables DMX controllers to send signals to Casambi-controlled fixtures

• Connects between a 12–24VDC Class 2 power supply and a DMX master controller

• Supports up to 8 Casambi pushbutton devices

• Ideal for RGBW and tunable white (TW) applications

• Multiple DMXcas units can be mapped independently across zones, fixtures, or channels

• Fully configurable via the Casambi app (free on iOS + Android)

• Acts like a virtual pushbutton within the Casambi network

• Compatible with up to 250-unit mesh networks for scalable control systems

This is an In-Stock Standard Item, however, please confirm availability with your Casambi Representative or Customer Service. Need more info on the product specs? The specification sheet has all the details.

FIND A CASAMBI REP NEAR YOU

DOWNLOAD SPEC SHEET
